GE 469

GE Power Management 469 Motor Management Relay 6-63
6 COMMUNICATIONS 6.4 MEMORY MAP
6
14 General Sw. D
15 Capture Trace
16 Simulate Pre-Fault
17 Simulate Fault
18 Simulate Pre-Fault...Fault
FC111 Unsigned
16 bit integer
TRIP RELAYS
0Trip
1Trip & Aux2
2 Trip & Aux2 & Aux3
3Trip & Aux3
FC112 Unsigned
16 bit integer
NOT DEFINED
0
1
FC113 Unsigned
16 bit integer
ALARM RELAYS
0Alarm
1Alarm & Aux2
2 Alarm & Aux2 & Aux3
3Alarm & Aux3
4Aux2
5Aux2 & Aux3
6Aux3
FC114 Unsigned
16 bit integer
COUNTER TYPE
0Increment
1Decrement
FC115 Unsigned
16 bit integer
ALARM / TRIP TYPE SELECTION
0Off
1Latched
2Unlatched
FC116 Unsigned
16 bit integer
SWITCH TYPE
0 Normally Open
1 Normally Closed
FC117 Unsigned
16 bit integer
RESET MODE
0 All Resets
1Remote Reset Only
2Keypad Reset Only
Table 6–2: MEMORY MAP DATA FORMATS (Sheet 5 of 14)
FORMAT
CODE
TYPE DEFINITION
FC118 Unsigned
16 bit integer
SHORT CIRCUIT RELAYS
0Trip
1Trip & Aux2
2 Trip & Aux2 & Aux3
3Trip & Aux3
4Aux2
5Aux2 & Aux3
6Aux3
FC119 Unsigned
16 bit integer
BACKUP RELAYS
0Aux2
1Aux2 & Aux3
2Aux3
FC120 Unsigned
16 bit integer
RTD TYPE
0 100 Ohm Platinum
1120 Ohm Nickel
2100 Ohm Nickel
310 Ohm Copper
FC121 Unsigned
16 bit integer
RTD APPLICATION
0None
1 Stator
2Bearing
3Ambient
4Other
FC122 Unsigned
16 bit integer
RTD VOTING SELECTION
1RTD #1
2RTD #2
3RTD #3
4RTD #4
5RTD #5
6RTD #6
7RTD #7
8RTD #8
9RTD #9
10 RTD #10
11 RTD #11
12 RTD #12
Table 6–2: MEMORY MAP DATA FORMATS (Sheet 6 of 14)
FORMAT
CODE
TYPE DEFINITION
