A.1 COMMISSIONING APPENDIX A
A
Table A–3: SETPOINTS PAGE 3 – DIGITAL INPUTS (Sheet 1 of 2)
DESCRIPTION DEFAULT USER VALUE DESCRIPTION DEFAULT USER VALUE
STARTER STATUS VIBRATION SWITCH TRIP
Starter Status Sw. Start Aux A Assign Trip Relays Trip
ASSIGNABLE DIGITAL INPUTS Vibration Switch Trip Delay 5.0 s
Input 1 Function Off DIGITAL COUNTER
Input 2 Function Off Counter Units Units
Input 3 Function Off Counter Preset Value 0
Input 4 Function Off Counter Type Increment
REMOTE ALARM Counter Alarm Off
Remote Alarm Name Remote Alarm Assign Alarm Relays Alarm
Remote Alarm Unlatched Counter Alarm Level 100
Assign Alarm Relays Alarm Counter Alarm Pickup Over
Remote Alarm Events Off Counter Alarm Events Off
REMOTE TRIP TACHOMETER
Remote Trip Name Remote Trip Rated Speed 3600 RPM
Assign Trip Relays Trip Tachometer Alarm Off
SPEED SWITCH TRIP Assign Alarm Relays Alarm
Assign Trip Relays Trip Tachometer Alarm Speed 10% Rated
Speed Switch Trip Delay 5.0 s Tachometer Alarm Delay 1 s
LOAD SHED TRIP Tachometer Alarm Events Off
Assign Trip Relays Trip Tachometer Trip Off
PRESSURE SWITCH ALARM Assign Trip Relays Trip
Block Alarm From Start 0 s Tachometer Trip Speed 10% Rated
Pressure Switch Alarm Unlatched Tachometer Trip Delay 1 s
Assign Alarm Relays Alarm GENERAL SWITCH A
Pressure Switch Alarm Delay 5.0 s Switch Name General Sw. A
Pressure Switch Alarm Events Off General Switch State Normally Open
PRESSURE SWITCH TRIP Block Input From Start 0 s
Block Trip From Start 0 s General Switch Alarm Off
Assign Trip Relays Trip Assign Alarm Relays Alarm
Pressure Switch Trip Delay 5.0 s General Switch Alarm Delay 5.0 s
VIBRATION SWITCH ALARM General Switch Events Off
Vibration Switch Alarm Unlatched General Switch Trip Off
Assign Alarm Relays Alarm Assign Trip Relays Trip
Vibration Switch Delay 5.0 s General Switch Trip Delay 5.0 s
Vibration Switch Alarm Events Off
