APPENDIX A A.1 COMMISSIONING
A
GENERAL SWITCH B GENERAL SWITCH D
Switch Name General Sw. B Switch Name General Sw. D
General Switch State Normally Open General Switch State Normally Open
Block Input From Start 0 s Block Input From Start 0 s
General Switch Alarm Off General Switch Alarm Off
Assign Alarm Relays Alarm Assign Alarm Relays Alarm
General Switch Alarm Delay 5.0 s General Switch Alarm Delay 5.0 s
General Switch Events Off General Switch Events Off
General Switch Trip Off General Switch Trip Off
Assign Trip Relays Trip Assign Trip Relays Trip
General Switch Trip Delay 5.0 s General Switch Trip Delay 5.0 s
GENERAL SWITCH C
Switch Name General Sw. C
General Switch State Normally Open
Block Input From Start 0 s
General Switch Alarm Off
Assign Alarm Relays Alarm
General Switch Alarm Delay 5.0 s
General Switch Events Off
General Switch Trip Off
Assign Trip Relays Trip
General Switch Trip Delay 5.0 s
Table A–3: SETPOINTS PAGE 3 – DIGITAL INPUTS (Sheet 2 of 2)
DESCRIPTION DEFAULT USER VALUE DESCRIPTION DEFAULT USER VALUE
