A.1 COMMISSIONING APPENDIX A
A
Table A–4: SETPOINTS PAGE 4 – OUTPUT RELAYS
DESCRIPTION DEFAULT USER VALUE
RELAY RESET MODE
R1 Trip Reset Mode All Resets
R2 Auxiliary Reset Mode All Resets
R3 Auxiliary Reset Mode All Resets
R4 Alarm Reset Mode All Resets
R5 Block Start Reset Mode All Resets
R6 Service Reset Mode All Resets
FORCE OUTPUT RELAY
Force R1 Output Relay Disabled
Force R1 Operation Time Static
Force R2 Output Relay Disabled
Force R2 Operation Time Static
Force R3 Output Relay Disabled
Force R3 Operation Time Static
Force R4 Output Relay Disabled
Force R4 Operation Time Static
Force R5 Output Relay Disabled
Force R5Operation Time Static
