GE 469

A-8 469 Motor Management Relay GE Power Management
A.1 COMMISSIONING APPENDIX A
A
Table A–8: SETPOINTS PAGE 8 – RTD TEMPERATURE
DESCRIPTION DEFAULT USER VALUE DESCRIPTION DEFAULT USER VALUE
RTD TYPES OPEN RTD SENSOR
Stator RTD Type 100 Ohm
Platinum
Open RTD Sensor Alarm Off
Assign Alarm Relays Alarm
Bearing RTD Type 100 Ohm
Platinum
Open RTD Sensor Alarm Events Off
RTD SHORT/LOW TEMP.
Ambient RTD Type 100 Ohm
Platinum
RTD Short/Low Temp Alarm Off
Assign Alarm Relays Alarm
Other RTD Type 100 Ohm
Platinum
RTD Short/Low Tmp. Alrm Events Off
RTD APPLICATION NAME ALARM ASSIGN ALARM
RELAYS
ALARM TEMP. ALARM EVENTS
1
2
3
4
5
6
7
8
9
10
11
12
RTD TRIP TRIP VOTING ASSIGN TRIP
RELAYS
TRIP TEMP. HIGH ALARM HIGH ALARM
RELAYS
HIGH ALARM
TEMPERATURE
1
2
3
4
5
6
7
8
9
10
11
12
