GE 469

CHAPTER 1: GETTING STARTED
469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL 1–5
To enter a given Settings page,
Z Press the
MESSAGE X or ENTER key.
Z Press the
MESSAGE T or MESSAGE S keys to scroll through sub-page
headers until the required message is reached.
The end of a page is indicated by the message
END OF PAGE. The
beginning of a page is indicated by the message
TOP OF PAGE.
To access actual values,
Z Press the
MENU key until the display shows the header of the actual
values menu.
Z Press the
MESSAGE X or ENTER key to display the header for the first
actual values page.
The actual values pages are numbered, have an ‘A’ prefix for easy
identification and have a name, which gives a general idea of the
information available in that page.
Pressing the
MESSAGE T or MESSAGE S keys will scroll through all
the available actual values page headers. Actual values page headers
look as follows:
To enter a given actual values page,
Z Press the
MESSAGE X or ENTER key.
Z Press the
MESSAGE T or MESSAGE S keys to scroll through sub-page
headers until the required message is reached.
The end of a page is indicated by the message
END OF PAGE. The
beginning of a page is indicated by the message
TOP OF PAGE.
Similarly, to access additional sub-pages,
Z Press the
MESSAGE X or ENTER key to enter the first sub-page,
Z Press the
MESSAGE T or MESSAGE S keys to scroll through the
available sub-pages, until the desired message is reached.
The process is identical for both settings and actual values.
The following procedure illustrates the key sequence to access the Current Demand actual
values.
Z Press the
MENU key until you reach the actual values main menu.
Z Press
MESSAGE X or ENTER key to enter the first actual values page.

SETTINGS [
Z]
S1 RELAY SETUP
 ACTUAL
VALUES [Z]
A1 STATUS
