5–12 469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL
CHAPTER 5: SETTINGS
The following settings appear when the relay is ordered with the DeviceNet (D) option.
PATH: SETTINGS Z S1 469 SETUP ZV COMMUNICATIONS
Enter the dedicated MAC ID and baud rate as per the DeviceNet design (Refer to GEK-
106491C: 469 Communications Guide). The DeviceNet option is implemented by the 469
relay using the AnyBus-S DeviceNet (HMS) module as a communication adapter. The
module is ODVA certified and acts as a server between the relay and the DeviceNet
network.
The following master/slave connection objects are supported by the 469 DeviceNet
implementation:
• Explicit Messaging Connection
• Poll I/O Connection
• Change of State or Cyclic I/O Connection
The following objects have been implemented:
Refer to publication GEK-106491C: 469 Communications Guide for additional details
on the DeviceNet implementation.

COMMUNICATIONS [
SLAVE ADDRESS:
254
Range: 1 to 254 in steps of 1
MESSAGE
COMPUTER RS485
BAUD RATE: 9600
Range: 300, 1200, 2400, 4800, 9600,
19200
MESSAGE
COMPUTER RS485
PARITY: None
Range: None, Odd, Even
MESSAGE
FRONT PORT RS232
BAUD RATE: 19200
Range: 300, 1200, 2400, 4800, 9600,
19200
MESSAGE
DEVICENET MAC ID:
1
Range: 0 to 63
MESSAGE
DEVICENET
BAUD RATE: 125K
Range: 125K, 250K, 500K
Object Class
DeviceNet objects
Identity object 01h
Message Router object 02h
DeviceNet object 03h
Assembly object 04h
Connection object 05h
Acknowledge Handler object 2Bh
469 specific objects
I/O Data Input Mapping object A0h
Parameter Data Input Mapping object B0h
