GE 469

CHAPTER 5: SETTINGS
469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL 5–33
Setting the INPUT 1(4) FUNCTION to “Capture Trace” allows for trace capture upon
command via a switch input. The captured waveforms can be displayed with the relay
software. There are no additional settings associated with this value.
Simulate Pre-Fault
PATH: SETTINGS ZV S3 DIGITAL INPUTS ZV ASSIGNABLE INPUT 1(4)
Setting the INPUT 1(4) FUNCTION to “Simulate Pre-Fault” allows the user to start the
Simulate Pre-Fault mode as per the
S13 469 TESTING Z SIMULATION MODE Z SIMULATION
MODE
setting via a switch input. This is typically used for relay or system testing. There are
no additional Digital Input settings associated with this value.
Simulate Fault
PATH: SETTINGS ZV S3 DIGITAL INPUTS ZV ASSIGNABLE INPUT 1(4)
Setting the INPUT 1(4) FUNCTION to “Simulate Fault” allows the user to start the Simulate
Fault mode as per the
S13 469 TESTING Z SIMULATION MODE Z SIMULATION MODE setting via
a switch input. This is typically used for relay or system testing. There are no additional
Digital Input settings associated with this value.
Simulate Pre-Fault …Fault
PATH: SETTINGS ZV S3 DIGITAL INPUTS ZV ASSIGNABLE INPUT 1(4)
Setting the INPUT 1(4) FUNCTION to “Sim Pre-Fault.Fault” allows the user to start the
Simulate Pre-Fault to Fault mode as per the
S13 469 TESTING Z SIMULATION MODE Z
SIMULATION MODE setting via a switch input. This is typically used for relay or system
testing. There are no additional Digital Input settings associated with this value.

ASSIGNABLE [
INPUT 1 FUNCTION:
Simulate Pre-
Range: See above.

ASSIGNABLE [
INPUT 1 FUNCTION:
Simulate Fault
Range: See above.

ASSIGNABLE [
INPUT 1 FUNCTION:
Sim Pre-
Range: See above.
