GE 469

CHAPTER 5: SETTINGS
469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL 5–43
Custom Overload Curve
If the SELECT CURVE STYLE is set to “Custom” in the Thermal Model, the following settings
will appear:
PATH: SETTINGS ZV S5 THERMAL MODEL ZV OVERLOAD CURVE SETUP

OVERLOAD [
TIME TO TRIP AT
1.01 x FLA:
Range: 0.5 to 99999.9 s in steps of 0.1
MESSAGE
TIME TO TRIP AT
1.05 x FLA:
Range: 0.5 to 99999.9 s in steps of 0.1
MESSAGE
TIME TO TRIP AT
1.10 x FLA:
Range: 0.5 to 99999.9 s in steps of 0.1
MESSAGE
TIME TO TRIP AT
1.20 x FLA: 795.4
Range: 0.5 to 99999.9 s in steps of 0.1
MESSAGE
TIME TO TRIP AT
1.30 x FLA: 507.2
Range: 0.5 to 99999.9 s in steps of 0.1
MESSAGE
TIME TO TRIP AT
1.40 x FLA: 364.6
Range: 0.5 to 99999.9 s in steps of 0.1
MESSAGE
TIME TO TRIP AT
1.50 x FLA: 280.0
Range: 0.5 to 99999.9 s in steps of 0.1
MESSAGE
TIME TO TRIP AT
1.75 x FLA: 169.7
Range: 0.5 to 99999.9 s in steps of 0.1
MESSAGE
TIME TO TRIP AT
2.00 x FLA: 116.6
Range: 0.5 to 99999.9 s in steps of 0.1
MESSAGE
TIME TO TRIP AT
2.25 x FLA: 86.1
Range: 0.5 to 99999.9 s in steps of 0.1
MESSAGE
TIME TO TRIP AT
2.50 x FLA: 66.6
Range: 0.5 to 99999.9 s in steps of 0.1
MESSAGE
TIME TO TRIP AT
2.75 x FLA: 53.3
Range: 0.5 to 99999.9 s in steps of 0.1
MESSAGE
TIME TO TRIP AT
3.00 x FLA: 43.7
Range: 0.5 to 99999.9 s in steps of 0.1
MESSAGE
TIME TO TRIP AT
3.25 x FLA: 36.6
Range: 0.5 to 99999.9 s in steps of 0.1
MESSAGE
TIME TO TRIP AT
3.50 x FLA: 31.1
Range: 0.5 to 99999.9 s in steps of 0.1
MESSAGE
TIME TO TRIP AT
3.75 x FLA: 26.8
Range: 0.5 to 99999.9 s in steps of 0.1
MESSAGE
TIME TO TRIP AT
4.00 x FLA: 23.3
Range: 0.5 to 99999.9 s in steps of 0.1
MESSAGE
TIME TO TRIP AT
4.25 x FLA: 20.5
Range: 0.5 to 99999.9 s in steps of 0.1
MESSAGE
TIME TO TRIP AT
4.50 x FLA: 18.2
Range: 0.5 to 99999.9 s in steps of 0.1
