1–12 469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL
CHAPTER 1: GETTING STARTED
îš„
SETTINGS [
Press MESSAGE X or ENTER
îš„
SETTINGS [
Press MESSAGE T
îš„
SETTINGS [
Press
MESSAGE X
or ENTER
îš„
CURRENT [
Press
MESSAGE X
or ENTER
PHASE CT PRIMARY:
600 A
Press
MESSAGE T
MOTOR FULL LOAD
AMPS
Press the VA L U E keys until 318 A is
displayed, or enter the value directly via
the numeric keypad.
MOTOR FULL LOAD
AMPS
Press the ENTER key to store the
settings.
NEW SETTINGS
HAS
