CHAPTER 1: GETTING STARTED
469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL 1–13
To set the ground CT ratings, modify the S2 SYSTEM SETUP ZV CURRENT SENSING ZV
GROUND CT
and the S2 SYSTEM SETUP ZV CURRENT SENSING ZV GROUND CT PRIMARY
settings as shown below.
Z Press the
MENU key until the relay displays the Settings menu header.

SETTINGS [
Press MESSAGE X or ENTER

SETTINGS [
Press MESSAGE T

SETTINGS [
Press
MESSAGE X
or ENTER

CURRENT [
Press
MESSAGE X
or ENTER
PHASE CT PRIMARY:
600 A
Press
MESSAGE T
MOTOR FULL LOAD
AMPS
Press
MESSAGE T
GROUND CT:
Multilin CT 50/
Press the VA L U E keys until
“5 A Secondary” is displayed.
GROUND CT:
5 A Secondary
Press the ENTER key to store the
settings.
NEW SETTINGS
HAS
Press
MESSAGE T
GROUND CT PRI-
MARY:
Press the VA L U E keys until 50 A is
displayed, or enter the value directly via
the numeric keypad.
GROUND CT PRI-
MARY:
Press the ENTER key to store the
settings.
NEW SETTINGS
HAS
