5–106 469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL
CHAPTER 5: SETTINGS
MESSAGE
SPEED2 TRIP AT
3.00 x FLA: 43.7
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
3.25 x FLA: 36.6
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
3.50 x FLA: 31.1
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
3.75 x FLA: 26.8
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
4.00 x FLA: 23.2
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
4.25 x FLA: 20.5
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
4.50 x FLA: 18.2
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
4.75 x FLA: 16.2
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
5.00 x FLA: 14.6
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
5.50 x FLA: 12.0
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
6.00 x FLA: 10.0
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
6.50 x FLA: 8.5 s
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
7.00 x FLA: 7.3 s
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
7.50 x FLA: 6.3 s
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
8.00 x FLA: 5.6 s
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
10.0 x FLA: 5.6 s
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
15.0 x FLA: 5.6 s
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
20.0 x FLA: 5.6 s
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 MIN ALLOW-
ABLE
Range: 70 to 95% in steps of 1
MESSAGE
SPEED2 ISTALL @
MIN
Range: 2.00 to 15.00 x FLA in steps of
0.01
MESSAGE
SPEED2 SAFE STALL
@
Range: 0.5 to 999.9 s in steps of 0.1
