GE 469

CHAPTER 5: SETTINGS
469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL 5–105
Refer to Custom Overload Curve on page 5–43 for additional details on the custom
overload curves available for Speed2.
• Voltage Dependent Overload Curves
If the
SELECT CURVE STYLE is set to “Voltage Dependent” in the Thermal Model, the
following settings will appear:
PATH: SETTINGS ZV S14 2-SPEED MOTOR Z SPEED2 OVERLOAD SETUP
MESSAGE
SPEED2 TRIP AT
7.50 x FLA: 6.3 s
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
8.00 x FLA: 5.6 s
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
10.0 x FLA: 5.6 s
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
15.0 x FLA: 5.6 s
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
20.0 x FLA: 5.6 s
Range: 0.5 to 99999.9 in steps of 0.1

SPEED2 [
SPEED2 TRIP AT
1.01 x FLA:
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
1.05 x FLA:
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
1.10 x FLA:
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
1.20 x FLA: 795.4
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
1.30 x FLA: 507.2
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
1.40 x FLA: 364.6
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
1.50 x FLA: 280.0
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
1.75 x FLA: 169.7
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
2.00 x FLA: 116.6
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
2.25 x FLA: 86.1
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
2.50 x FLA: 66.6
Range: 0.5 to 99999.9 in steps of 0.1
MESSAGE
SPEED2 TRIP AT
2.75 x FLA: 53.3
Range: 0.5 to 99999.9 in steps of 0.1
