GE Advisor MASTER ATS111 series

51
Example:
YES – Card Only
* - Change 0 - Skip
Example:
YES – Privileged
* - Change 0 - Skip
Example:
YES –Extended Access
* - Change 0 - Skip
8. If the user number that you are programming is higher than 1000, then all options available have been
programmed and the display returns to step 1.
If the system has been programmed so that users do not have name files, or if you are programming a user
higher than 200, skip to step 10.
The display shows:
Your Name is , (*)-End
9. You can now enter a user’s name of up to 16 characters, by using the text option on the keypad.
Keys 1 to 9 have alphabetical characters printed above them. To enter a letter, press the key the number of
times relative to the position of the letter. Both upper and lower case letters are available as well as the
numerical values. See Figure 2 for details.
Do one of the following options:
Option Action
Enter the letters of the user name
Enter each letter of the user name followed
by [ENTER]
Move the cursor to the position after the name Press [ENTER]
Save the name (and display the new name if programmed/changed)
If the name has been changed, only letters preceding the cursor are saved
Press [MENU*]
10. When finished entering the name, press [MENU*] to save the displayed setting, and skip the remaining
user flags.
 Caution: when programming name text, the [ENTER] key is ONLY used to move the cursor. Follow the procedure carefully
when programming name text. Use [MENU*] to save and exit.
11. The display shows:
Example:
PIN Code:
Code:
12. Enter the PIN code for this user (see Notes 3, 4, 5, and 6) and press [ENTER] to save the PIN code. In
case no special memory mode is selected, press [ENTER] again to return to step 1.
The ATS control panel has a Card Learn feature available when the special memory mode is enabled (soft
IUM) that will enable an easy method of connecting users to card numbers. For this purpose, you assign a
