Appendix B. Optional Enclosures
DigitalFlow™ GS868 Service Manual 54
U4
I/O
CH2
CH1
Pin 1
Nut & Washers (typ.)
Standoff (typ.)
Display ShroudLCD Display
Keypad Cable
Backlight Cable
Black Lead
Red Lead
Display Cable
Analog Output Connector
CH1 Transducer Connector
CH2 Transducer Connector
EPROM (U4)
PCB Mounting Screw (typ.)
Printed Circuit Board
Option Card Bracket
Option Card Socket
(typ.)
RS232 Connector
Ground Lead (Green)
Option Card Slot Cover
Snap Rivets (typ.)
Beveled Corner
Top Panel Mounting Hole
Power Terminal Block
Line Lead (Black)
Neutral Lead (White)
Fuse
4 places
Figure 11: Model GS868 Rack Mount Console Assembly - (ref. dwg #705-849)
