Chapter 1. Installation
DigitalFlow™ GF868 Startup Guide (1 and 2-Channel) 17
1
4.24
5.10 (129)
13.00 13.49
8.00 (203)
1.40 (36)
10.74 (273)
1.54 (39)
1.65 (42)
2.26 (57)
1.50 (38)
1.77 (45)
1.30 (33)
2.26 (57)
1.20 (30)
1/2" Conduit Plate
11.37 (289)
3/4" Conduit Plate
2.87
7.00
2.69 (68)
0.75 (19)
Ø0.38 (10), 4 Places
Ø0.13 (3), 4 Places
Ø0.88 (22), 10 Places
Ø1.10 (28), 6 Places
(362) (330) (343)
(73)
(178)
Figure 8: Model GF868 Type 4X Enclosure (ref. dwg #425-208)
