DigitalFlow™ XGM868i Startup Guide 43
Chapter 3. Operation
Chapter 3. Operation
3.1 Introduction
See Chapter 1, Installation, and Chapter 2, Initial Setup, to prepare the Model XGM868i system for operation. When
the meter is ready to take measurements, proceed with this chapter. The following specific topics are discussed:
• Powering Up
• Using the Display
• Taking Measurements
• Recording Diagnostics
Note: All inputs and outputs of the Model XGM868i are calibrated at the factory, prior to shipment. If it becomes
necessary to recalibrate any of the inputs and/or outputs, see Chapter 1, Calibration, of the Service Manual for
instructions.
WARNING! To ensure the safe operation of the Model XGM868i, it must be installed and operated as
described in this manual. In addition, be sure to follow all applicable local safety codes and
regulations for the installation of electrical equipment.
