DigitalFlow™ XGM868i Startup Guide 63
Appendix B. Data Records
Appendix B. Data Records
B.1 Available Option Cards
The Model XGM868i can hold one option card in Slot 1 and one in Slot 2. The available configurations are listed in
Table 14 below.
Table 14: Option Card Configurations
Card # Slot # Configuration
1215-02 1 FF - 4 Frequency Outputs
1215-03 TT - 4 Totalizer Outputs
1215-04 FT - 2 Frequency Outputs/2 Totalizer Outputs
1215-05 FO - 2 Frequency Outputs
1215-06 TO - 2 Totalizer Outputs
1215-07 AA - 4 Standard Alarms
1215-09 FA - 2 Frequency Outputs/2 Standard Alarms
1215-11 TA - 2 Totalizer Outputs/2 Standard Alarms
1223-02/1473-02 OI - 2 Current Inputs
1223-03/1473-03 OR - 2 RTD Inputs
1223-04/1473-04 TI - 2 Current Inputs/2 Totalizer Outputs
1223-05/1473-05 TR - 2 RTD Inputs/2 Totalizer Outputs
1223-06/1473-06 FI - 2 Current Inputs/2 Frequency Outputs
1223-07/1473-07 FR - 2 RTD Inputs/2 Frequency Outputs
1223-08/1473-08 AI - 2 Current Inputs/2 Standard Alarms
1223-10/1473-10 AR - 2 RTD Inputs/2 Standard Alarms
1225-13 CO - 2 Current Outputs
1225-14 CF - 2 Current Outputs/2 Frequency Outputs
1225-15 CT - 2 Current Outputs/2 Totalizer Outputs
1225-16 CA - 2 Current Outputs/2 Standard Alarms
1430-03 RR - 4 RTD Inputs
1430-04 IR - 2 RTD Inputs/2 Current Inputs
1146-02/1332-02 2 128 KB Memory
1146-03/1332-03 2 MB Memory
1345-04 Modbus Communications Protocol
1385 HART Communication
1477-03 2 MODBUS/TCP/IP
1477-01 2 Ethernet
1475-01 2 Foundation Fieldbus
