DigitalFlow™ XMT868i Startup Guide 63
Chapter 4. Specifications
4.2.5 Additional Options
PC-Interface Software:
PanaView™ software option links the XMT868i to a PC. Software package includes CD and manual.
4.3 Transducer
4.3.1 Wetted Transducers
Material:
Standard: 316 Stainless Steel
Optional (for isolating PanAdapta Plugs
): Hastelloy, Monel, Titanium, Duplex, CPVC, PVDF and others
Process Connection:
Standard: 1-in. NPTM, 3/8-in. NPTM
Optional: RF flange, socket weld, fuse bond and others
Maximum Pressure:
Standard: 0 to 3,000 psig (0.1013 to 20 MPa)
Optional: Higher pressures on request
Temperature Range:
Standard: –40° to 212°F (–40° to 100°C)
Optional (overall range): -310
o
to 932
o
F (-190 to 500
o
C)
Mounting:
Spoolpiece, hot tap, or cold tap
Area Classifications:
Standard: General-purpose
Optional:
Explosion proof: Class I, Div. 1, Groups B, C & D; Class II, Groups E, F and G; Class III
Flameproof: II 2 G EEx d IIC T6
Weatherproof: Type 4/IP65
Submersible
Note: Wetted transducers for special applications and flowcells are also available. Consult the factory for details.
