Chapter 4. Specifications
64 DigitalFlow™ XMT868i Startup Guide
4.3.2 Clamp-On Transducers
Temperature Range:
Standard: –40° to 300°F (–40° to 150°C)
Optional (overall range): -310
o
to 572
o
F (-190
o
to 300
o
C)
Mounting:
Stainless steel chain or strap, welded or magnetic clamping fixtures
Area Classifications:
Standard: General-purpose
Optional:
Explosion proof: Class I, Div. 1, Groups B, C & D; Class II, Groups E, F and G; Class III
Flameproof: II 2 G EEx md IIC T6-T3
Weatherproof: Type 4/IP65
Submersible
Note: Clamp-on transducers for special applications and flowcells are also available. Consult the factory for details.
4.3.3 Transducer Cables
Length:
Standard: Pair of coaxial cables, type RG62 aU, length to 3 ft (1 m)
Optional: Lengths up to 1000 ft (330 m) maximum
4.3.4 Temperature Transducers (optional)
Type:
Loop-powered 3-wire platinum RTDs; clamp-on and wetted (thermowell) types are available
Range:
-4
o
F to 500
o
F (-20
o
C to 260
o
C), not all extremes of parameters can be achieved simultaneously
Accuracy:
0.27
o
F (0.15
o
C), wetted RTDs, matched pairs
