CHAPTER 15: PROGRAMMING QUICK REFERENCE
GE Multilin EPM 5000 series Advanced Power Meters 87
06. KYZ Programming
06P. Pulse Factor Programming
060. KYZ Port 0 Function Mapping
061. KYZ Port 1 Function Mapping
062. KYZ Port 2 Function Mapping
07. Number of Phases
15.5: Group 1: Full Scale Setup
10. Volts Full Scale
11. Currents Full Scale
12. Power Full Scale
15.6: Group 2: Calibration
20. Volt AN, BN, CN
21. Amp A, B, C (High End)
22. Amp A, B, C (Low End)
15.7: Group 3: Calibration Ratios
30. Volt AN
31. Volt BN
32. Volt CN
33. Amp A (High-End Ratios)
34. Amp B (High-End Ratios)
35. Amp C (High-End Ratios)
36. Amp A (Low-End Ratios)
37. Amp B (Low-End Ratios)
38. Amp C (Low-End Ratios)
15.8: Group 4: Volt/Current Limits
40. Volt AN, Volt BN, and Volt CN Limits.
41. Volt AB, Volt BC, and Volt CA Limits.
42. Amp A, Amp B, and Amp C Limits.
43. Amp N Limits.
