Hydran* M2-X Ins
tallation Guide
Page
38
MA
-
028
Rev. 2.1,
11
-Jun-
20
Setting the Netw
ork Communicati
on Parameters
Go to
Main Menu
Select
Setup
Press
Enter
Select
Comm
Setup
Press
Enter
Select
Identification
Press
Enter
Change, as required:
Monitor ID
Power Station ID
37
39
