IRECTION 5273008-100, REVISION 9 LOGIQ C BASIC SERIES SERVICE MANUAL
3 - 16 Section 3-6 - System Configuration
3-6-5-5 Connect Peripherals (cont’d)
C.) Connect Foot Switch to the system.
Foot Switch can be properly connected using USB Ports.
D.) Connect the USB Memory to the system. The USB Memory can be properly connected using USB
ports.
E.) ECG can be properly connected using USB ports. (ECG only supported by LOGIQ C5/C5 PRO)
Figure 3-11 Connect Foot Switch to the system
Figure 3-12 USB Memory Connection
Figure 3-13 ECG
