GE HEALTHCARE
DIRECTION 5162630, REVISION 3 LOGIQ™ S6 SERVICE MANUAL
Section 6-6 - Jumper and Dip Switch Setting 6-29
6-6-3-2 Accessing Dip Switch Module for inspection (cont’d)
2.) Remove the RS232C board from the VCR to access the dip switch.
6-6-4 CP30D Dip Switch Setting
This section describes CP30D Dip Switch setting. Field Service Engineer (FSE) is not allowed to modify
dip switch setting. Following setting is documented for purpose of troubleshooting by FSE.
Figure 6-110 Removing Board
NOTICE
D
Do NOT change the DIP SW setting!!
Figure 6-111 CP30D Dip Switch (All OFF)
Dip Switch
RS232C Board
1 2 3 4 5 6 7 8
ON
OFF
