DIRECTION 5162630, REVISION 3 LOGIQ™ S6 SERVICE MANUAL
Section 9-4 - Renewal Parts List For BT08, LCD with BECOMP3 9-7
9-4-2 BT08 with BECOMP3 Parts
Figure 9-192 BT08 with BECOMP3 Parts
Table 9-72 BT08 with BECOMP3 Parts
Item Part Name Part Number Description Qty FRU
- 17 inch IPS-PRO Type 5261237
for forward production of BT08 or later
(including the LCD field Upgrade system to BT08 or
later) Model Name: GA500C
11
1 LCD ARM2 5257403 for use with 17" IPS-PRO type monitor only 1 1
2 EBUS 4T ASSY 5182215 Upper EBUS for forward production of BT08 or later 1 1
3 EBUS 4B ASSY 5182757 Lower EBUS for forward production of BT08 or later 1 1
4 DDBF128 ASSY 5182379
board in nest, slot 6 (for forward production of BT08
or later)
1 1
5 AGP BOARD ASSY 2362887
for CRT monitor system and forward production of
BT08 or later
1 1
1
2
3
4
5
6
7
8
9
10
11
