GE HEALTHCARE
DIRECTION 5162630, REVISION 3 LOGIQ™ S6 SERVICE MANUAL
Section 9-5 - Renewal Parts List for Original LOGIQ S6 (BT06) 9-17
Table 9-78 OP Panel and Keys
Item Part Name Part Number Description Qty FRU
70 KEYBOARD FOR CRT 5170515 For use with R6.x.x Systems only 1 1
70 KEYBOARD FOR CRT 5170515-2 Full Compatibility (R6/R7) for CRT system 1 1
71 OP PANEL ENCODER Assy 2317341 all encoders with cables 1 1
72 OP PANEL TGC Assy 5123003 for keyboard Assy version (2299986-8) or higher 1 1
73 TGC KNOB SET 2356244 TGC plastic knobs only 1 2
74 OP PANEL A/N KEY BOARD Assy 2317343-2 PCB board and alphanumeric keyboard 1 1
75 GREEK AN KEYTOP OPTION 5181098 1 1
76 RUSSIAN AN KEYTOP OPTION 5181031 1 1
77 OP PANEL TRACKBALL 2317344 LOGIQ3 common 1 1
78 OP PANLE LCD Assy 2317346-3 CIRCUIT board 1 1
79 LCD ENCODER Assy 5122999 for keyboard Assy version (2299986-8) or higher 1 1
80 P KEY LABEL 2364143 USER DEFINE key label 1 2
81 FREEZE KEY 5122997
Freeze key, PCB and cables included.
For keyboard Assy version (2299986-8) or higher
11
82 KEYBOARD MAIN BOARD 5122993 For keyboard Assy version (2299986-8) or higher 1 1
83 KEY CAP SET 2390710
plastic key cover cap set - Printer (P2, P3, and P4),
LOGIQ View, Contrast, 3D Harmonics, 2 blank key
cap and 1 pc of B Flow clear cap
12
84 CAP SET 5170215 6 pcs 1 2
85 KBD FOR LCD (S6 LCD) 5170397 For use with R6.x.x Systems only 1 1
85 KBD FOR LCD (S6 LCD) 5170397-2 Full Compatibility (R6/R7) for LCD System 1 1
86 SWEDISH AN KEYTOP OPTION 5193888 1 1
87
NORWEGIAN DANISH AN KEYTOP
OPTION
5193889 1 1
