GE HEALTHCARE
DIRECTION 5162630, REVISION 3 LOGIQ™ S6 SERVICE MANUAL
Section 9-5 - Renewal Parts List for Original LOGIQ S6 (BT06) 9-19
Table 9-79 Front End Assemblies
Item Part Name Part Number Description Qty FRU
90 EBUS 3T ASSY 5111348
Upper EBUS for backward production before BT08
(including the software,LCD field upgrade system to
BT08 or later)
11
91 EBUS 3B ASSY 5112465
Lower EBUS for backward production before BT08
(including the software,LCD field upgrade system to
BT08 or later)
11
94 PREA2F ASSY 5119039 board in nest, slot 1 1 1
95 BTRAPP5AHV Assy 5154321 board in nest, slot 3 - 4 1 1
96 BTxCW ASSY 5111346 Installed on the HBTRAP (Option) 1 1
97 DDBF64 ASSY 2399312
board in nest, slot 5 - 6 (for backward production
before BT08.
Including the software,LCD field upgrade system to
BT08 or later.)
1 1
99 STCW ASSY 2277244-4 board in nest, slot 2 (option) (Not Shown) 1 1
100 MDBRG2S ASSY 5145999 board in nest, slot 9 1 1
101 TRICON Assy 5170473 without sheet metal attachment 1 1
102 BACK PLANE 5138460 1 1
103 NEST Board JIG Assy 2315492
Tools to remove a board in the NEST Assy (Not
Shown)
1 2
104 Tx CABLES Assy CSL L7 2305111-3 4 1
To Next Page
