DIRECTION 5162630, REVISION 3 LOGIQ™ S6 SERVICE MANUAL
Section 9-5 - Renewal Parts List for Original LOGIQ S6 (BT06) 9-23
Table 9-80 Back End Assemblies
Item Part Name Part Number Description Qty FRU
110 SVP-BECOMP3-NP 5193189 without Video card/FALCON 1 1
111 Battery Pack LOGIQ7 2304809-2 1 1
112 DGPCIO VIC 2-A ASSY 5133526
for backward production before BT08
(including the software,LCD field upgrade system to
BT08 or later)
11
113 Extended MEMORY3 LOGIQ7 5118511 option 1 1
114 HD LOGIQ7 5118510 1 1
115 PC2IP 2B FC200656
for backward production before BT08
(including the software,LCD field upgrade system to
BT08 or later)
1 1
116 Capture Board 5147460 1 1
117 AGP BOARD ASSY 2362887
for CRT monitor system and forward production of
BT08 or later
11
118 PAT. I/O FA200801 option (ECG) 1 1
119 DVD drive 6 5150568-2 1 1
120 MO Drive LOGIQ7 5113449 (Not support forward production of BT08 or later) 1 1
121 MO Panel CSL LS6 5169668 1 1
122 HDD Extension Cable LOGIQ7 5122012 1 1
123 PCI Cable 2389075 1 1
124 EMC Parts L7 5149429 1 1
127 EXTENDED USB PORT 2384469 2 1
129 BECOMP3 REAR FAN CSL L7 5142743 1 1
130 PC BOX FAN ASSY 2305014 1 1
131 DUAL DVI AGP (Not Shown) 5111298-2
for backward LCD production before BT08
(including the software,LCD field upgrade system to
BT08 or later)
11
132 PCI VGA (Not Shown) 5121039
for backward LCD production before BT08
(including the software,LCD field upgrade system to
BT08 or later)
11
To Next Page
