DIRECTION 5162630, REVISION 3 LOGIQ™ S6 SERVICE MANUAL
Section 1-2 - Important Conventions 1-7
“CAUTION - Dangerous voltage” (the
lightning flash with arrowhead in
equilateral triangle) is used to indicate
electric shock hazards.
Various
“General Warning Sign” Rear panel and UPS battery BT08 or later
“Warning” - Dangerous voltage” (the
lightning flash with arrowhead) is
used to indicate electric shock
hazards.
Rear panel and inside of console BT08 or later
“Mains OFF” Indicates the power off
position of the mains power switch.
Rear of system adjacent to mains
switch
“Mains ON” indicates the power on
position of the mains power switch.
Rear of system adjustment to mains
switch
“ON” indicates the power on position
of the power switch.
CAUTION
This Power Switch DOES NOT
ISOLATE Mains Supply
“Standby” indicates the power stand
by position of the power switch.
CAUTION
This Power Switch DOES NOT
ISOLATE Mains Supply
Adjacent to On/Standby Switch
“Protective Earth” Indicates the
protective earth (grounding) terminal.
Various
“Equipotentiality” Indicates the
terminal to be used for connecting
equipotential conductors when
interconnecting (grounding) with
other equipment.
Rear of console
Alternating Current symbol is in
accordance with IEC 60878-01-14.
Rear Panel, Rating Plate, Circuit
breaker label of console and front
panel (if applicable).
BT08 or later
Table 1-5 Warnings
Label/Symbol Purpose/Meaning Location Note
