GE LOGIQ V3 Service Manual

GE LOGIQ V5/LOGIQ V3
D
IRECTION 5496012-100, REVISION 3 BASIC SERVICE MANUAL
- 7 - 1
Chapter 7
Diagnostics/Troubleshooting
Section 7-1
Overview
7-1-1 Purpose of Chapter 7
This section describes how to setup and run the tools and software that help maintain image quality and
system operation. Very basic host, system and board level diagnostics are run whenever power is
applied. Some Service Tools may be run at the application level. However most software tests are
required.
Table 7-3 Contents in Chapter 7
Section Description Page Number
7-1
Overview
7-1
7-2
Gathering Trouble Data
7-2
7-3
Screen Captures
7-4
7-4
Common Diagnostics
7-7
7-5
Network Configuration
7-8
