3 - 14 Section 3-3 - Receiving and Unpacking the Equipment
3-6-4 Connecting Cables
3-6-5 Peripherals/Accessories Connector Panel
LOGIQ V5/LOGIQ V3 peripherals and accessories can be properly connected using the side connector
panel.
3-6-5-1 Rear Panel Connector
NOTE: The AC printer can be connected to the isolated Printer USB port on the rear panel only.
WARNINGWARNING
Equipment damage possibility. Be sure to use the following recommended connecting cables to
connect recording devices and a network with LOGIQ V5/LOGIQ V3 console.
Table 3-9 List of Connecting Cables
Name Part No. Figure NOTE
USB Cable
For USB Printer
Figure 3-5 Rear Connector Panel
