Marquette Hellige GmbH MAC 1100/1200 V 1.1 Page 37
227 492 20 D - 0002
The following table shows the most important combinations:
Device
model
Inter-
pretation
Output
formats
Languages Default settings
Override
function
enabled
Line filter
01 INT HEART international international no 50 Hz
02 USA 12SL USA e,f,s yes 60 Hz
03 Europe2 12SL international international yes 50 Hz
04 ASIA *) HEART international international no 50 Hz
05 RUSS HEART international g,e,f,r,hung,
czech
no 50 Hz
- Language international: g, e, f, i, s, por, sw, nor, fin, dan, hol, czech, hung
- Europe 2: United Kingdom, Benelux, Scandinavia
*) not available from version V1.1
The required device model is selected by pressing the appropriate key, “1" to “5".
Quit selection menu by pressing the “X“ key.
Quit the self-test with “X” key.
MAC 1200 configures the appropriate items and initiates a cold start automatically.
Thus, when the device is rebooted automatically all the new settings are adopted.
Selecting a particular device model leads to the configuration of the program for
Interpretation as indicated in the table above, even when the interpretation program
was configured differently beforehand as described in Section 3.14.
Note on saved ECGs when configuring the device model:
Saved ECGs are not lost.
If a new device model is selected, the program for Interpretation is switched over;
however, when printing out the saved ECGs the display in the status line (12SL, or
without in the case of HEART) is related to the currently enabled program for
Interpretation, although the results are based on the program previously configured. In
this case, the saved ECGs should be printed out or transferred to a PC before
configuration of the new model.
