Marquette Hellige GmbH MAC 1100/1200 V 1.1 Page 8
227 492 20 D - 0002
Variants of the MAC1100/1200
The complete list of the variants is included in Section 8 “Parts List”.
The following table gives an overview of the different device models of the
MAC1100/1200.
With version V1.1, the ASIA device models are identical to the INTERNATIONAL
device models, because the Manufacturer ID is GE marquette in general now, so
special ASIA device models are not required any longer.
Device Device Model Manufacturer
ID
Keypad Labeling Mains Voltage
MAC1100
MAC1200
INT GE marquette Icons International 230V
MAC1100
MAC1200
Europe 2 GE marquette Text International 230V
MAC1200 USA GE marquette Text USA 115V
MAC1100
MAC1200
RUSS GE marquette Kyrillian International 230V
Hardware functional blocks:
MAC1100 and MAC1200 comprises of the same hardware functional blocks.
Differences between both are mentioned.
List of the main functional blocks:
Switching power supply
NC Battery for MAC1100 only as an option
PCB NC Battery charge for MAC1100 only as an option
PCB Control CS_CI
PCB Modem Supply CS_M for MAC1200 US device only,
from version V1.1
Printing unit
Keypad
¼ VGA graphics display, monochrome
The description of the functional blocks is valid for MAC1100 and MAC1200.
Differences between MAC1100 and MAC1200 in single functional blocks are
mentioned within the description of such blocks.
