18 MM200 MOTOR MANAGEMENT SYSTEM – QUICK START GUIDE
CONFIGURATION SETPOINTS CHAPTER 3: SETPOINTS
Full-voltage reversing
Two-speed
NOTE
NOTE:
By selecting a pre-defined starter, inputs and outputs are automatically assigned.
Common motor
setpoints
Several motor setpoints are dependent on the chosen starter type. The setpoints shown
below are common to all starter types.
Motor Name
Range: up to 20 alphanumeric characters
Default: Motor Name
This setpoint specifies a name for the motor. This name will appear in the actual values.
Starter Type (Mandatory setpoint)
Range: None, FV Non-Reversing, FV Reversing, Two Speed
Default: FV Non-Reversing
This setpoint selects the starter type. The relay is essentially disabled when the value is
set to “None”. Figure 1 illustrates typical starter timing beginning from the stopped state
for all starter types.
Motor FLA (Mandatory setpoint)
Range: 0.5 to 1000.0 amps in steps of 0.1
Default: OFF
This setpoint must be specified for motor protection. The value may be taken from the
motor nameplate data sheets.
Supply Frequency (Mandatory setpoint)
Range: 50 Hz, 60 Hz
Default: 60 Hz
This setpoint specifies the nominal system frequency.
The following sections provide additional information for each starter type.
