CHAPTER 13: RAPID SPANNING TREE PROTOCOL RAPID SPANNING TREE PROTOCOL
MULTILINK ML1200 MANAGED FIELD SWITCH – INSTRUCTION MANUAL 13–11
Configuring RSTP (continued)
RSTP CONFIGURATION
-----------------
Rapid STP/STP Enabled(Global) : YES
RSTP/STP Enabled Ports : 1,2,3,4,5,6,7
Protocol : Normal RSTP
Bridge ID : 80:00:00:20:06:2b:e1:55
Bridge Priority : 32768
Bridge Forward Delay : 15
Bridge Hello Time : 02
Bridge Max Age : 20
Root Port : 0
Root Path Cost : 0
Designated Root : 80:00:00:20:06:2b:e1:55
Designated Root Priority : 32768
Root Bridge Forward Delay : 15
Root Bridge Hello Time : 02
Root Bridge Max Age : 20
Topology Change count : 0
Time Since topology Chg : 1371
ML1200(rstp)##
show-timers
Forward Delay Timer : 15 sec
Hello Timer : 2 sec
Max Age : 20 sec
ML1200(rstp)##
show stp ports
RSTP Port Configuration
-------------------------------------------------------------------------------
Port# Type Priority Path Cost State Des. Bridge Des. Port
-------------------------------------------------------------------------------
01 TP(10/100) 128 2000000 Forwarding 80:00:00:20:06:2b:e1:55 00:01
02 TP(10/100) 128 200000 Forwarding 80:00:00:20:06:2b:e1:55 00:02
03 100MB Fiber 128 200000 Disabled 00:03
04 100MB Fiber 128 200000 Disabled 00:04
05 100MB Fiber 128 200000 Disabled 00:05
06 100MB Fiber 128 200000 Disabled 00:06
07 TP(10/100) 128 2000000 Disabled 00:07
ML1200(rstp)##
priority port=2 value=100
