NX-8E CONTROL
24
L LOCATION 42 - GO TO PROGRAM CODE (6 segments, numerical data)
Location 42 contains the "Go To Program Code". This location contains either a 4 or 6-digit code. If the 6-digit
code option is enabled in Location 41, THIS CODE MUST CONTAIN SIX (6) DIGITS. If this option is not
enabled in location 41, the last 2 segments (digits) will be ignored. With the NX-8E disarmed, the "Go To
Program Code" can be used to enter the Program Mode.
LOCATION 43 - GO TO PROGRAM CODE PARTITION AND AUTHORIZATION (2 segments, feature
selection)
The "Go To Program Code" can be used as a standard arm/disarm code. When using the code to arm or disarm,
the user ID is 255. (This code may not be changed in the Run Mode.)
Segment 1: 1 - Reserved.
2 - On enables "Go To Program Code" as an arm only code.
3 - On enables "Go To Program Code" as an arm only after closing.
4 - On enables "Go To Program Code" as a master arm/disarm code (can change user codes)
5 - On enables "Go To Program Code" as an arm/disarm code.
6 - On enables "Go To Program Code" to bypass zones.
7 - On enables "Go To Program Code" opening and closing reports.
8 - Reserved.
Segment 2: 1 - On enables the "Go To Program Code" for Partition #1.
2 - On enables the "Go To Program Code" for Partition #2.
3 - On enables the "Go To Program Code" for Partition #3.
4 - On enables the "Go To Program Code" for Partition #4.
5 - On enables the "Go To Program Code" for Partition #5.
6 - On enables the "Go To Program Code" for Partition #6.
7 - On enables the "Go To Program Code" for Partition #7.
8 - On enables the "Go To Program Code" for Partition #8.
L LOCATION 44 - DURESS CODE (6 segments, numerical data)
Location 44 contains the "Duress" code. This Location contains either 4 or 6 digits. If the 6-digit code option is
enabled in Location 41, THIS CODE MUST CONTAIN SIX (6) DIGITS. If the 6-digit option is not enabled in
location 41, the last 2 digits will be ignored. If the duress code is programmed, it will work for all partitions.
LOCATION 45 - AUXILIARY OUTPUT 1-4 PARTITION SELECTION (4 segments, feature selection data)
Location 45 is used to select which partition(s) the events must occur in before the output will activate. Location
45 has 4 segments. Segment 1 corresponds to output 1, and Segment 4 corresponds to output 4.
Segment 1 (Aux 1)
Segment 2 (Aux 2) Segment 3 (Aux 3) Segment 4 (Aux 4)
1= Partition #1 1= Partition #1 1= Partition #1 1= Partition #1
2= Partition #2 2= Partition #2 2= Partition #2 2= Partition #2
3= Partition #3 3= Partition #3 3= Partition #3 3= Partition #3
4= Partition #4 4= Partition #4 4= Partition #4 4= Partition #4
5= Partition #5 5= Partition #5 5= Partition #5 5= Partition #5
6= Partition #6 6= Partition #6 6= Partition #6 6= Partition #6
7= Partition #7 7= Partition #7 7= Partition #7 7= Partition #7
8= Partition #8 8= Partition #8 8= Partition #8 8= Partition #8
LOCATION 46 - AUXILIARY OUTPUT 1-4 SPECIAL TIMING (4 segments, feature selection data)
Location 46 contains special timing feature activation for the four auxiliary outputs. Segment 1 corresponds to
output 1; Segment 4 corresponds to output 4.
Segments 1 - 4: 1 = On if output should be timed in minutes; Off if timed in seconds.
2 = On if output should latch; Off if output should be timed.
3 = On if output should stop timing upon code entry; Off if the output should continue to time
upon code entry.
4 = On if output should only activate between the closing and opening time in loc. 52 and 53.
5 = On if output should only activate between the opening and closing time in loc. 52 and 53.
6 = On if output should be inverted (0 volts going to 12 volts when activated).
7 = Reserved.
8 = Reserved.
