GE NetworX Series Installation And Start-Up Manual

NX-8E CONTROL
58
LOC PG DESCRIPTION DEFAULT DATA
PARTITION 8, ENTRY/EXIT TIMERS
Segment #1 (Entry Time #1) 0 _
Segment #2 (Exit Time #1) 0 _
Segment #3 (Entry Time #2) 0 _
Segment #4 (Exit Time #2) 0 _
109 32
Segment #5 & #6 RESERVED
110 33 ZONE TYPE 1 ALARM EVENT CODE 8 _
ZONE TYPE 1 CHARACTERISTIC SELECT
Segment #1 (Circle numbers to program)
1
2
3
4
Fire (enable for fire zone).
24 Hour (enable for non-fire 24 hour
zone).
Keyswitch zone.
Follower (enable for burg zones that are
instant during non-entry times).
5
6
7
8
Delay 1 zone (enable to follow Timer 1 Entry/Exit
times).
Delay 2 zone (enable to follow Timer 2 Entry / Exit
times).
Interior (Enable for auto bypass or stay arming).
Local Only (enable if zone is not to be reported).
Segment #2 (Circle numbers to program)
111 33
1
2
3
4
Keypad audible on alarm.
Yelping siren on alarm.
Temporal siren on alarm.
Chime.
5
6
7
8
Bypassable.
Group Shunt.
Force armable.
Entry Guard.
Segment #3 (Circle numbers to program)
1
2
3
4
Fast Loop Response.
Double End of Line Tamper zone.
Trouble zone (Day zone).
Cross Zone.
5
6
7
8
Dialer Delay zone.
Swinger zone.
Restore reporting.
Listen-In.
Segment #4 (Circle numbers to program)
1
2
3
4
Zone Activity Monitor.
End of Line Resistor Defeat.
Delays alarm activation 60 seconds.
Zone acts as request to exit input.
5
6
7
8
Reserved.
Reserved.
Reserved.
Reserved.
Segment #5 - Reserved
THE DEFAULTS LISTED IN THE ODD NUMBERED LOCATIONS BELOW REPRESENT THE THREE SEGMENTS OF
EACH OF THOSE LOCATIONS. USE THE THREE SEGMENT CHARTS FROM LOCATION 111 TO UNDERSTAND
THESE DEFAULTS.
LOC PG DESCRIPTION DEFAULT DATA
112 33 ZONE TYPE 2 ALARM EVENT CODE 2 __
113 33 ZONE TYPE 2 CHARACTERISTIC SELECT 2-125-78-0-0 __ __ __ __ __
114 33 ZONE TYPE 3 ALARM EVENT CODE 7 __
115 33 ZONE TYPE 3 CHARACTERISTIC SELECT 5-1245-5678-0-0 __ __ __ __ __
116 34 ZONE TYPE 4 ALARM EVENT CODE 5 __
117 34 ZONE TYPE 4 CHARACTERISTIC SELECT 45-125-5678-0-0 __ __ __ __ __
118 34 ZONE TYPE 5 ALARM EVENT CODE 5 __
119 34 ZONE TYPE 5 CHARACTERISTIC SELECT 457-125-5678-0-0 __ __ __ __ __
120 34 ZONE TYPE 6 ALARM EVENT CODE 4 __
121 34 ZONE TYPE 6 CHARACTERISTIC SELECT 0-1245-5678-0-0 __ __ __ __ __
122 34 ZONE TYPE 7 ALARM EVENT CODE 0 __
123 34 ZONE TYPE 7 CHARACTERISTIC SELECT 2-0-78-0-0 __ __ __ __ __
124 34 ZONE TYPE 8 ALARM EVENT CODE 1 __
125 34 ZONE TYPE 8 CHARACTERISTIC SELECT 1-13-378-0-0 __ __ __ __ __
126 34 ZONE TYPE 9 ALARM EVENT CODE 7 __
127 34 ZONE TYPE 9 CHARACTERISTIC SELECT 6-1245-5678-0-0 __ __ __ __ __
128 34 ZONE TYPE 10 ALARM EVENT CODE 2 __
129 34 ZONE TYPE 10 CHARACTERISTIC SELECT 24-5-78-0-0 __ __ __ __ __

GE NetworX Series Specifications

General

Model	NetworX Series
Zones	Varies by model (e.g., 8, 16, 32, 64)
Partitions	Varies by model (typically 1-8)
Keypads	Supports multiple keypads
Communication	Phone line, cellular, IP
Power Supply	16.5 VAC
Backup Battery	12VDC, 7AH
User Codes	Varies by model (e.g., 48, 150, 300)
Event Buffer	Varies by model (e.g., 200, 500, 1000 events)
Operating Temperature	0°C to 49°C (32°F to 120°F)
Communication Protocol	Contact ID, SIA
Weight	Varies by model
Dimensions	Varies by model (e.g., 14.5" x 12.5" x 3.5")
