GE NetworX Series Installation And Start-Up Manual

NX-8E CONTROL
59
LOC PG DESCRIPTION DEFAULT DATA
130 34 ZONE TYPE 11 ALARM EVENT CODE 3 __
131 34 ZONE TYPE 11 CHARACTERISTIC SELECT 3-0-0-0-0 __ __ __ __ __
132 35 ZONE TYPE 12 ALARM EVENT CODE 5 __
133 35 ZONE TYPE 12 CHARACTERISTIC SELECT 457-125-45678-0-0 __ __ __ __ __
134 35 ZONE TYPE 13 ALARM EVENT CODE 4 __
135 35 ZONE TYPE 13 CHARACTERISTIC SELECT 0-12458-5678-0-0 __ __ __ __ __
136 35 ZONE TYPE 14 ALARM EVENT CODE 7 __
137 35 ZONE TYPE 14 CHARACTERISTIC SELECT 5-12456-5678-0-0 __ __ __ __ __
138 35 ZONE TYPE 15 ALARM EVENT CODE 5 __
139 35 ZONE TYPE 15 CHARACTERISTIC SELECT 457-1256-5678-0-0 __ __ __ __ __
140 35 ZONE TYPE 16 ALARM EVENT CODE 4 __
141 35 ZONE TYPE 16 CHARACTERISTIC SELECT 0-12456-5678-0-0 __ __ __ __ __
142 35 ZONE TYPE 17 ALARM EVENT CODE 7 __
143 35 ZONE TYPE 17 CHARACTERISTIC SELECT 5-1245-25678-0-0 __ __ __ __ __
144 35 ZONE TYPE 18 ALARM EVENT CODE 5 __
145 35 ZONE TYPE 18 CHARACTERISTIC SELECT 457-125-25678-0-0 __ __ __ __ __
146 36 ZONE TYPE 19 ALARM EVENT CODE 4 __
147 36 ZONE TYPE 19 CHARACTERISTIC SELECT 0-1245-25678-0-0 __ __ __ __ __
148 36 ZONE TYPE 20 ALARM EVENT CODE 7 __
149 36 ZONE TYPE 20 CHARACTERISTIC SELECT 6-1245-25678-0-0 __ __ __ __ __
150 36 ZONE TYPE 21 ALARM EVENT CODE 15 __
151 36 ZONE TYPE 21 CHARACTERISTIC SELECT 24-15-78 __ __ __ __ __
152 36 ZONE TYPE 22 ALARM EVENT CODE 20 __
153 36 ZONE TYPE 22 CHARACTERISTIC SELECT 24-15-78 __ __ __ __ __
154 36 ZONE TYPE 23 ALARM EVENT CODE 21 __
155 36 ZONE TYPE 23 CHARACTERISTIC SELECT 24-15-78 __ __ __ __ __
156 36 ZONE TYPE 24 ALARM EVENT CODE 22 __
157 36 ZONE TYPE 24 CHARACTERISTIC SELECT 1-13-378 __ __ __ __ __
158 36 ZONE TYPE 25 ALARM EVENT CODE 14 __
159 36 ZONE TYPE 25 CHARACTERISTIC SELECT 248-45-0-0-0 __ __ __ __ __
160 37 ZONE TYPE 26 ALARM EVENT CODE 5 __
161 37 ZONE TYPE 26 CHARACTERISTIC SELECT 467-125-5678-0-0 __ __ __ __ __
162 37 ZONE TYPE 27 ALARM EVENT CODE 5 __
163 37 ZONE TYPE 27 CHARACTERISTIC SELECT 457-1257-5678-0-0 __ __ __ __ __
164 37 ZONE TYPE 28 ALARM EVENT CODE 7 __
165 37 ZONE TYPE 28 CHARACTERISTIC SELECT 6-12457-5678-0-0 __ __ __ __ __
166 37 ZONE TYPE 29 ALARM EVENT CODE 5 __
167 37 ZONE TYPE 29 CHARACTERISTIC SELECT 457-125-5678-1-0 __ __ __ __ __
168 37 ZONE TYPE 30 ALARM EVENT CODE 7 __
169 37 ZONE TYPE 30 CHARACTERISTIC SELECT 5-1245-5678-1-0 __ __ __ __ __
L
170 37 ZONES 49-56, ZONE TYPES 6-6-6-6-6-6-6-6 _ _ _ _ _ _ _ _
ZONES 49-56, PARTITION SELECTION (Segment 1=Zone 49 thru Segment 8=Zone 56)
Segments 1 2 3 4 5 6 7 8
171 37
Partition #1
Partition #2
Partition #3
Partition #4
Partition #5
Partition #6
Partition #7
Partition #8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
