GE NX-10 Installation Guide

NX-10 Expander Installation Guide
35
LOC PG DESCRIPTION DEFAULT YOUR DATA
243 27 PROGRAMMING THE ZONES
Seg
1
Door Shunt Zone 0 = Disabled
Seg
2
Request to Exit (RTE) 0 = Disabled
244 27 READER TIMES
Seg
1
Scan Time (1/100 seconds) 100 = 1 second
Seg
2
Relay Active Time (seconds) 10 = 10 seconds
Seg
3
Door Fault Warning Time
(seconds)
30 = 30 seconds
Seg
4
Door Fault Alarm Time
(seconds)
0 = 0 seconds
245 28 RESET THE READER ADDRESS
CAUTION: Entering a “0” will
reset and cause the reader to cease
functioning.
246 28 PROGRAMMING THE ACCESS OPTIONS
Seg
1
DOOR OPTIONS
"On" if locking mechanism is a Maglock or Drop Bolt.
"On" if access is allowed regardless of Armed status of the system.
"On" if the door is not to be latched unlocked during an open schedule.
"On" if onboard open collector output only triggers during an open schedule.
“On” if onboard open collector output only triggers during a close schedule.
“On” if Forced Entry Alarm is logged.
“On” if access allowed without an RTE.
"On" if relay operates normally during off-schedule
Seg
2
SCHEDULES FOR ONBOARD OPEN COLLECTOR OUTPUT
"On" if driver follows Schedule 1.
"On" if driver follows Schedule 2.
"On" if driver follows Schedule 3.
"On" if driver follows Schedule 4.
"On" if driver follows Schedule 5.
"On" if driver follows Schedule 6.
"On" if driver follows Schedule 7.
"On" if driver follows Schedule 8.
Seg
3
MORE DOOR OPTIONS
