GE NX-10 Installation Guide

4 Disarm
5 Activate Aux/KeyFob Function 1 (see control panel events)
6 Activate Aux/KeyFob Function 2 (see control panel events)
7 Broadcast an X-10 function (see Location 1)
8
Send a Request to Exit (RTE) and activate the relay output. (Default is On.) Location 3,
Segment 2 must be programmed with a valid zone number for the RTE to be sent.
Segment 3 Triple Badge Function
1 Send Code Entry function to the control panel
2 Arm Away
3 Arm Stay mode
4 Disarm
5 Activate Aux/KeyFob Function 1 (see control panel events)
6 Activate Aux/KeyFob Function 2 (see control panel events)
7 Broadcast an X-10 function (see Location 241)
8
Send a Request to Exit (RTE) and activate the relay output. (Default is On.) Location 3,
Segment 2 must be programmed with a valid zone number for the RTE to be sent.
“Send Code Entry” function: By choosing the function, “Code Entry”, the reader sends a function to the control panel
along with user number and authority that says such and such user entered a code. Scanning a card then
acts just like a user entering their code on a keypad.
Location 1 Set the X-10 Address for the Badge Functions (5 segments of numerical data)
Segment 1
Program a number from 0-15 to represent the corresponding X-10 Unit Code
from the following table. (Default is 0)
Unit 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Seg 1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Segment 2
Program a number from 0-15 to represent the corresponding X-10 House code
from the following table. (Default is 0)
X-10 ADDRESS CODES
0=A 4=E 8=I 12=M
1=B 5=F 9=J 13=N
2=C 6=G 10=K 14=O
3=D 7=H 11=L 15=P
Segment 3
Single Badge Function. Program the X-10 function that is performed when a card
is badged once. This location only needs to be programmed if Location 0,
Segment 1, Option 7 is set. (Default is 2.)
Function no. Function performed
0 All units off
1 All lights on
2 On
3 Off
