NX-10 Expander Installation Guide
53
4 Dim
5 Bright
6 All lights off
All others Reserved
Segment 4
Double Badge Function. Program the X-10 function that is performed when a card
is badged and held at the reader for the duration of the Scan Time (Location 4,
Segment 1). The descriptions of the function codes are the same as for Single
Badge Function (see table above). This location only needs to be programmed if
Location 0, Segment 2, Option 7 is set. (Default is 3.)
Segment 5
Triple Badge Function. Program the X-10 function that is performed when a card is
badged and held at the reader for the duration of 2 times the Scan Time (Location
4, Segment 1). The descriptions of the function codes are the same as for Single
Badge Function (see table above). This location only needs to be programmed if
Location 0, Segment 3, Option 7 is set. (Default is 2.)
Location 2 Programming the Options and Reader Partitions (4 segments of binary data)
Segment 1
System Options
1
On if reader is enabled for User Card Programming.
2
On if tamper is enabled.
3
On if reader buzzer is to follow typical keypad buzzing.
(Default is On.)
4
On if ding-dong chime enabled (dependant on option 3 and chime being enabled).
5
On if a Request to Exit (RTE) from a scanned card is to be logged as Code Entry. (Default
is On.)
6
On if an RTE from a zone or the Egress input is to be logged as Code Entry.
7
Reserved.
8
On if beep on RF loss enabled.
Segment 2
System Options (cntd):
1
Reserved.
2
Bypass Hide. When system is armed, all bypassed zones LED’s are off.
3
Reserved.
4
Reserved.
5
Disable Service. An option that turns off the Service LED.
6
LED Extinguish. An option that turns off all the status LEDs.
7
Reserved.
8
Reserved.
