NX-10 Expander Installation Guide
87
10 System low battery 31** Closed schedule 52
Flash X-10 for alarm
memory
11** Duress 32 Listen in 53 Flash X-10 for siren
12** Manual fire 33 Line seizure 54
Armed in ‘Exit’ mode, after
exit time
13** Manual medical alarm 34
Failed to
communicate
55 End listen-in
14** Keypad panic 35 Telephone line fault 56
Compare X-10 commands
with X-10 addresses
(activate exit by means of
DTMF commands
15
Keypad tamper (wrong
codes)
36 Program mode 57 Disarmed : state of zone
Armed : latch
16** Automatic test 37 Download 58 Service required
17 Alarm memory 38
Follow zone status in
alarm
59 Armed in “STAY” mode
18 Entry 39
Over current (12
Vdc)
60 Sensor low battery
19 Exit 40 Box tamper 61 Sensor missing (lost)
20 Entry or exit 41 Siren tamper 62 B-alarm
* See locations 52 and 53 in installation manual of NetworX control panel
** If set to follow condition, these events will be 1 second
♦ Events 46 and 47 require wireless receivers to operate
♠ Events 48, 49 and 50 will arm or disarm the NetworX control panel at the open (disarm) or close (arm) time for
the appropriate schedule.
LOCATION 1 - PROGRAMMING SPECIAL FUNCTIONS AND PARTITIONS FOR OUTPUT 1 (2
segments, feature selection data)
Segment 1 - selects the following special conditions
Option Function
ON If output should time in minutes 1
OFF If output times in seconds
ON Output “Latch”: should latch until a code is entered 2
OFF Output is timed
ON Timed or output should be reset if a code is entered while it is being timed 3
OFF Stays timed (not reset) after code is entered
4 ON If output should only trigger during a closed schedule
5 ON If output should only trigger during an open schedule
6 ON If the output should be inverted (from 0 Volt to 12 Volt when activated)
7 ON If a trigger should be logged in the event buffer (see chart)
8 Reserved
Address 24 25 26 27 28 29 30 31
To Next Page
