Output 1-8 9-16 17-24 25-32 33-40 41-48 49-56 57-64
Segment 2 - selects the following partitions
Option Function
1 ON If the event should activate when it occurs in partition 1
2 ON If the event should activate when it occurs in partition 2
3 ON If the event should activate when it occurs in partition 3
4 ON If the event should activate when it occurs in partition 4
LOCATION 2 - ENABLING THE SCHEDULES FOR OUTPUT 1 (1 segment, feature selection data)
Location 2 is used to enable any or all of the eight (8) schedules. This location can be used in
conjunction with the special function location to create an output that will only activate during certain
times and/or certain days.
Option Function
1 ON If the event should follow schedule 1
2 ON If the event should follow schedule 2
3 ON If the event should follow schedule 3
4 ON If the event should follow schedule 4
5 ON If the event should follow schedule 5
6 ON If the event should follow schedule 6
7 ON If the event should follow schedule 7
8 ON If the event should follow schedule 8
LOCATION 3 - PROGRAMMING THE X-10 LOCATION FOR OUTPUT 1 (2 segments, numerical
data)
Segment 1 - Module number
Program a number from 0-15 to represent the corresponding X-10 module number from the
following table.
Module 1 2 3 4 5 6 7 8 9
1
0
1
1
1
2
1
3
1
4
1
5
1
6
Segm 1 0 1 2 3 4 5 6 7 8 9
1
0
1
1
1
2
1
3
1
4
1
5
Segment 2 - House code
Program a number from 0-15 to represent the corresponding house code from the following table.
X-10 Location code (house code)
0=A 4=E 8=I 12=M
1=B 5=F 9=J 13=N
2=C 6=G 10=K 14=O
3=D 7=H 11=L 15=P
