GE NX-10 Installation Guide

NX-10 Expander Installation Guide
99
LOC DESCRIPTION DEFAULT PROGRAMMING DATA
Segment 1 (Circle Numbers To Program)
1 ON: if timed in minutes. OFF: if timed is seconds
2 ON: If latched until code is entered. OFF: for timed
3 ON: If output should stop timing when a code is entered. OFF: timed
4 ON: If output should only trigger during a closed schedule
5 ON: If output should only trigger during an open schedule
6 ON: If the output should be inverted
7 ON: If a trigger should be logged in the event buffer
8 Reserved
Segment 2 (Circle Numbers To Program)
1 Partition 1
2 Partition 2
3 Partition 3
4 Partition 4
OUTPUT 8: SCHEDULE
1 Schedule 1 5 Schedule 5
2 Schedule 2 6 Schedule 6
3 Schedule 3 7 Schedule 7
30
4 Schedule 4 8 Schedule 8
OUTPUT 8: X-10 ADDRESS
1 Module number
0
31
2 House code
0
32 SCHEDULE 1 OPENING TIME
8 0
33 SCHEDULE 1 CLOSING TIME
20 0
SCHEDULE 1 DAYS (Circle the numbers to program)
1
Sunday
5 Thursday
2 Monday 6 Friday
3 Tuesday 7
Saturday
34
4 Wednesday 8
Disabled on holidays
35 SCHEDULE 2 OPENING TIME
8 0
36 SCHEDULE 2 CLOSING TIME
20 0
SCHEDULE 2 DAYS (Circle the numbers to program)
1
Sunday
5 Thursday
2 Monday 6 Friday
3 Tuesday 7
Saturday
37
4 Wednesday 8
Disabled on holidays
38 SCHEDULE 3 OPENING TIME
8 0
39 SCHEDULE 3 CLOSING TIME
20 0
SCHEDULE 3 DAYS (Circle the numbers to program)
1
Sunday
5 Thursday
2 Monday 6 Friday
3 Tuesday 7
Saturday
40
4 Wednesday 8
Disabled on holidays
41 SCHEDULE 4 OPENING TIME
8 0
42 SCHEDULE 4 CLOSING TIME
20 0
SCHEDULE 4 DAYS (Circle the numbers to program)
1
Sunday
5 Thursday
2 Monday 6 Friday
3 Tuesday 7
Saturday
43
4 Wednesday 8
Disabled on holidays
44 SCHEDULE 5 OPENING TIME
8 0
45 SCHEDULE 5 CLOSING TIME
20 0
