GE NX-10 Installation Guide

LOC DESCRIPTION DEFAULT PROGRAMMING DATA
OUTPUT 5: X-10 ADDRESS
1 Module number
0
19
2 House code
0
20 OUTPUT 6: EVENT, ZONE, TIME
43 6 10
OUTPUT 6: SPECIAL FEATURES & PARTITIONS
Segment 1 (Circle Numbers To Program)
1 ON: if timed in minutes. OFF: if timed is seconds
2 ON: If latched until code is entered. OFF: for timed
3 ON: If output should stop timing when a code is entered. OFF: timed
4 ON: If output should only trigger during a closed schedule
5 ON: If output should only trigger during an open schedule
6 ON: If the output should be inverted
7 ON: If a trigger should be logged in the event buffer
8 Reserved
Segment 2 (Circle Numbers To Program)
1 Partition 1
2 Partition 2
3 Partition 3
21
4 Partition 4
OUTPUT 6: SCHEDULE
1 Schedule 1 5 Schedule 5
2 Schedule 2 6 Schedule 6
3 Schedule 3 7 Schedule 7
22
4 Schedule 4 8 Schedule 8
OUTPUT 6: X-10 ADDRESS
1 Module number
0
23
2 House code
0
24 OUTPUT 7: EVENT, ZONE, TIME
43 7 10
OUTPUT 7: SPECIAL FEATURES & PARTITIONS
Segment 1 (Circle Numbers To Program)
1 ON: if timed in minutes. OFF: if timed is seconds
2 ON: If latched until code is entered. OFF: for timed
3 ON: If output should stop timing when a code is entered. OFF: timed
4 ON: If output should only trigger during a closed schedule
5 ON: If output should only trigger during an open schedule
6 ON: If the output should be inverted
7 ON: If a trigger should be logged in the event buffer
8 Reserved
Segment 2 (Circle Numbers To Program)
1 Partition 1
2 Partition 2
3 Partition 3
25
4 Partition 4
OUTPUT 7: SCHEDULE
1 Schedule 1 5 Schedule 5
2 Schedule 2 6 Schedule 6
3 Schedule 3 7 Schedule 7
26
4 Schedule 4 8 Schedule 8
OUTPUT 7: X-10 ADDRESS
1 Module number
0
27
2 House code
0
28 OUTPUT 8: EVENT, ZONE, TIME
43 8 10
29 OUTPUT 8: SPECIAL FEATURES & PARTITIONS
