To replace the upper oven door:
Pull the hinges down away from the oven frame 1.
to the fully open position.
Lift up on the hinge locks and rotate toward the 2.
oven frame until they stop.
The hinges will release to the 45-degree position. 3.
The hinge locks will contact the oven frame.
Slide the door back onto the hinges. Make sure 4.
the buttons pop back out.
Fully open the door.5.
Rotate the hinge locks back toward the door 6.
and onto the hinge.
Close the oven door.7.
To remove the outer door assembly:
Remove the door. (See 1. Upper Oven Door
Assembly.)
Place the door assembly gasket side down on a 2.
protective surface.
Remove the 4 Phillips-head screws that attach 3.
the bottom of the outer door assembly to the
outer door.
Remove the six ¼-In. hex-head screws that 7.
attach the handle to the outer door assembly.
Remove the Phillips-head screw from each side 4.
of the outer door panel.
Remove four ¼-in. hex-head screws from each 8.
side of the outer door panel.
Slide the outer door glass down to clear the 6 9.
retaining tabs.
Tabs
Separate the outer door assembly from the 5.
inner door.
Place the outer door assembly handle side 6.
down on a protective surface.
