– 36 –
To replace the inner door assembly:
Remove the outer door assembly. (See previous 1.
page.)
Remove the four T-20 Torx screws (2 on each 2.
side) that attach each door hinge receiver to the
inner door.
Lower Oven Door Assembly
The lower oven door can be separated into 2
assemblies. The outer assembly consists of the
outer panel, outer glass, and a replaceable door
handle. The inner assembly is made up of the inner
panel, inner glass assembly, heat defl ector, heat
barrier, door gasket, and replaceable door hinge
assemblies.
Caution: The door is very heavy. Use the correct
lifting procedure. Do not lift the door by the handle.
To remove the lower oven door assembly:
Open the door fully.1.
Insert a fl at-blade screwdriver into the cut-out 2.
in each of the hinge door locks. Push the hinge
locks from the locked position down toward the
door frame, to the unlocked position.
Hinge Door Lock
Cut-out
Remove the insulation and the inner glass 5.
assembly from the inner door.
Place the inner door panel gasket side down.3.
Remove the seven ¼-in. hex-head screws that 4.
hold the heat barrier to the inner door panel.
Inner Glass Assembly
(Continued next page)
Firmly grasp both sides of the door at the top.3.
Close door to the door removal position.4.
