Convection Element
• The element is rated at 2500 watts, has an
approximate resistance value of 23 Ω, and
draws approximately 10 amps.
• The convection bake element is located on the
back wall of the lower oven and can be removed
from inside the oven cavity.
The convection element operates during the
following modes:
Preheat•
Convection Bake•
Convection Roast•
Clean•
To remove the convection bake element:
Remove oven racks. 1.
Remove the four ¼-in. hex-head screws that 2.
hold the convection cover to the back wall of the
oven cavity.
3. Remove the four ¼-in. hex-head screws that
hold the convection element to the back wall of
the oven cavity.
4. Carefully pull the convection element towards
the front of the oven until the element terminals
are accessible.
Disconnect the wires from the convection 5.
element.
Note: There is a gasket placed between the element
bracket and the oven cavity. Be sure to install the
gasket to its original location.
Convection Bake Element
