– 28 –
1. Remove 4 mounting screws located in the
front oven frame.
GEA00342
2. Slide the oven forward, out of the cabinet or
wall opening.
3. Lower the oven onto a protected surface for
further servicing.
Remove Oven Cavity Lamps
1. Remove the access panel at the rear of the
unit.
2. Remove 2 screws holding the lamp housing in
place.
GEA00442
ScrewsScrews
3. Slide the housing out from under the tabs.
GEA00443
TabsTabs
4. Rotate the lamp housing to replace the bulb
(WB36X10160).
Remove Outer Access Covers
To access all other electrical components
(excluding the left latch switch), one or more
covers must be removed.
WARNING: Before removing covers, remove all
power to the oven by turning off the appropriate
circuit breaker.
To Remove the Top Access Cover:
1. Remove 9 screws and lift off the cover.
To Remove the Right Access Cover:
1. Remove the top access cover (see previous
procedure).
2. Remove 8 screws on the right access cover
panel.
3. Lift off the cover.
