GE SCB2000 Technical Service Guide

– 52 –
GEA00522
Door Switches
OVEN DOOR OPEN POSITION
SWITCH
DESCRIPTION
SWITCH
CONTACTS
PRIMARY
DOOR MONITOR
DOOR SENSING
OPEN
CLOSED
OPEN
Door Closed
Door Open
Tab
GEA00540
Door Closed
Door Open
Tabs
GEA00541
Left Latch
Assembly
Right Latch
Assembly
All T.C.O.s are non-resettable (“one
shot”) except for the magnetron
T.C.O., which will reset at 140°F
(60°C).
GEA00430
THERMAL
FUSE
DOOR
SENSING
SWITCH
DAMPER
MOTOR
DAMPER DOOR OPERATING MODES
COOKING
MODE
DAMPER
POSITION
SW. PLUNGER
POSITION
SWITCH
CONTACTS*
MICROWAVE
SPEEDCOOK
OPEN
CLOSED
NOT DEPRESSED
DEPRESSED
CLOSED
OPEN
* Damper door sensing switch contacts are closed when
oven door is open.
